Automatic winding machine to operate, is not difficult, mainly for Winder unfamiliar, the company has no professional training in it, but then we are here to tell you,I beli-

eve that people do not understand just click methods to manipulate will understand. During the operation of automatic winding machine, be sure to know how to set a starting position around, wire size, wire winding width three important parameters.

Specific methods are as follows:

First,  the winding position setting

What is the winding position?Simply put, the starting point is at the start of the winding skeleton,The location and type of head coil and the coil are closely relati-

onship, Usually by the device control system comes with measurement function to measure the correlation values from specific winding position ;The operator can also be used manually measured ,at a fixed point as a reference point when attention coils with actual measurements using a ruler, set the winding should pay attention to the winding direction of the coil

Second, enameled specifications set

Our common wire has a different diameter,Wire specifications set correctly directly affect the effectiveness row wire,The use of different materials need to add a different diameter wire correction value, copper is not easy attenuated, the correction value plus about 0.02,Aluminum is easily stretched in tension after winding equipment and over the line device, the correction values are allowed between 0.02-0.2 of magnitude larger.

Third, the winding width settings

Winding Width can understand that From the start position to the winding end of the winding of the distance between the position,normally this value directly reflects the need for winding the length of the bobbin,when setting need to consider the slight deformation of the use of bobbin effect winding width, the method should be used as a comprehensive measure of taking the minimum wire width.
